DF 465 hp 4 x 2

DONGFENG KL dci465 4×2 TRACTOR HEAD

Chassis Dimensions	6560(L)x2550(W)x3900(H) mm
Wheelbase	4000mm
Curb weight (chassis)	7100kg
Engine
– Type	dci465-51
– Emission level	Euro V
– Maximum power	343kw at 1800rpm
– Maximum torque	2200N.m
– Maximum torque	2200N.m
– Number of cylinders	6
– Displacement (lit)	11.12L
– Cylinder bore (mm)	123mm
– Stroke (mm)	156mm
– System	Two-cylinder air compressor water Cooled, turbocharged, after cooled, high pressure common rail fuel system+SCR, cold start.
Gear box
– Type	DT1422(DD) (Volvo Manual)
– No. of gears	14 forward gears & 4 reverse, synchronized
Clutch Plate’s diameter	¢ 430mm (SACHS)
Clutch Operating System	Hydraulic control with air booster, pulling
Front Axle	Elliot type, I beam section. Load capacity 5.5 (ton)
Rear Axle	Single reduction, with wheel lock. Load capacity 13 (ton)
Brake System	Full air brake system, split pneumatic circuit ; parking spring brake acting on rear axles, exhaust brake, engine brake, ABS.
Tyres	12R22.5 18PR
Front Suspension	2Leaf spring
Rear Suspension	Shock absorber and stabilizer bar
Cab	Sleeper cab, high roof, two bunks bed, new face, electrical cab tilting, adjustable driver’s seat, air conditioning system, electric windows, central lock, cruise control, front guard installation.
Fuel tank Type & Capacity	Aluminium alloy tank, with lockable cap & 600 lit
Battery Voltage, Capacity	24 (V), 180×2 (A.h)
Fifth Wheel (mm)	50mm
Other	Maintenance-free wheel, fairwater, Slingshot, Autosculpt,LCD, tachographs, daytime light, LDWS.


